8.TROUBLESHOOTING

271

1) The control axis detach signal (DTCHn) is input.

#7 #6 #5 #4 #3 #2 #1 #0

G0124 DTCH2 DTCH1

If it is 1, the corresponding axis is detached.

2) The following parameter enables the control axis detach function to

the corresponding axis.

#7 #6 #5 #4 #3 #2 #1 #0

0012 RMVx

#7(RMVx) 0 : Controlled axis is connected

1 : Controlled axis is detached

Actual spindle speed does not arrive at a speed specified in a program.

Confirm the signal state using the PMC’s diagnostic function

(PMCDGN).

#7 #6 #5 #4 #3 #2 #1 #0

G0029 SAR

#4(SAR) : When this signal is 0, spindle speed does not arrive at the

specified speed.

This function is valid when PARAM SAR (3708#0)=1.

Normally manual feedrate override function is used for jog feed.

But when DRN(dry run) signal turns on during an auomatic

operation,override values set with these signals become valid to the

following speed set by a parameter.

#7 #6 #5 #4 #3 #2 #1 #0

G0046 DRN

#7(DRN) : Dry run signal is input with this signal being 1.

1410 Dry run rate for each axis [mm/min]

The rate when the following override value is 100%.

#7 #6 #5 #4 #3 #2 #1 #0

G0010 *JV7 *JV6 *JV5 *JV4 +JV3 *JV2 *JV1 *JV0

G0011 *JV15 *JV14 *JV13 *JV12 +JV11 *JV10 *JV9 *JV8

When override value is 0%, all bits of the above address is

[1111 1111] or [0000 0000].. . . . . . . .

*JV15 JV0. . . . . . . . . . . . . . Override

1111 1111 1111 1111

1111 1111 1111 1110

1101 1000 1110 1111

0000 0000 0000 0001

0000 0000 0000 0000

0.00%

0.01%

100.00%

655.34%

0.00%

In this case, the CNC’s status display shows RESET. Refer to item 1.

(1) Only rapid traverse in positioning (G00) does not function Confirm

the following parameter and signals from the PMC.

(a) Setting value of rapid traverse rate

1420 Rapid traverse rate for each axis [mm/min]

g.CNC is waiting for

spindle speed arrival

signal to be input

h.Manual feedrate override

is 0% (dry run)

i. Power Mate is in a reset

state
