9. TROUBLESHOOTING (SERIAL INTERFACE SPINDLE)

337

Item Cause of trouble Check procedure Remedy

Defective fan motor

of motor

Check if fan motor is

rotating.

Replace fan motor.

Overload operation Check cutting conditions

and how tools are worn.

Check load meter for

cutting.

Review cutting conditions

and tools.

Dirty motor cooling

system

Check motor cooling sys-

tem for dirt.

Clean motor cooling

system with an air gun or

vacuum cleaner.

Disconnection or

loose contact of

motor overheat

signal line

Check signal line connec-

tion status.

Connect signal line

correctly.

Item Cause of trouble Check procedure Remedy

Overload operation

(overload)

Check with load meter. Review cutting conditions

and tools.

Defective transistor

module

Check if transistor collec-

tor-emitter is open.

Replace transistor module.

Fuse for protecting

driver on PCB

blown or not in-

serted correctly

(disconnection,

loose contact, etc.)

Check if fuses F3A to F3M

(models 1S to 26S) or FA

to FG (models 30S and

40S) are blown or re-

moved.

Insert fuses firmly.

Replace any blown fuse.

Speed feedback

signal abnormality

Check level of speed feed-

back signal.

Check motor speed detec-

tor and signal cable con-

nection.

Wiring failure

(disconnection,

loose contact, etc.)

Check that cables are

connected correctly.

NOTE

How to check the speed feedback signal

Observe the speed feedback signal with an osciloscope

after turning on power and setting the rotation command off

(motor stopped and drive power set off).

Observe the test points indicated below, while turning the

motor slowly by hand.

9.2

TROUBLESHOOTING

FOR EACH ALARM

AL–01 Motor overheat

AL–02 Excessive speed

deviation
