B–62835EN/01

8.TROUBLESHOOTING

319

When the spindle amplifier does not become normal state immediately

after power is turned on in the serial spindle system, this alarm is

informed.

This alarm does not occur once the system becomes ready including the

spindle system .

This alarm occurs during power on sequence before the system becomes

ready.

After the system becomes ready, serial spindle alarm is issued by alarm

749.

(1) Cable is in poor contact or spindle amplifier power is off.

(2) When display of spindle amplifier shows SU–01 or an alarm other

than AL–24 is displayed, power to the CNC is turned on.

In this case, this alarm usually occurs when the CNC’s power is turned

off while the serial spindle is operating. Turn off the power of serial

spindle once, then turn it on and starts the system.

Confirm the details of troubles on diagnostic 409.

0409

#6 #5 #4 #3

SPE

#2 #1

S1E

SHE

DGN

#3(SPE) 0 : In spindle serial control, the serial spindle parameters satisfies the

starting conditions for spindle amplifier.

1 : In spindle serial control, the serial spindle parameters do not satisfy

the starting conditions for spindle amplifier.

#1(S1E) 0 : The serial communication module of the CNC side is normal.

1 : The serial communication module of the CNC side is abnormal.

#0(SHE) 0 : Serial spindle module on the CNC side is normal.

1 : Serial spindle module was detected to be abnormal on the CNC side.

Reform the following countermeasures based on the above configurations:

(1) #3(SPE)1: In spindle serial control, the serial spindle parameters

does not satisfy the starting conditions for spindle

amplifier.

↓

Confirm the settings of parameters 4000s.

Especially checks the parameters those are changed from the standard

parameters.

(2) #1(SIE)1: When an abnormality is found in the 1st spindle at the start

of serial spindle control, exchange the unit if the following

check items are not concerned.

↓

Check the parameters and connections at the 1st spindle to see

whether the 1st spindle is mechanically and electrically connected.

↓

If the parameters and connections are correct, the system control

module shown below or the spindle amplifier itself is faulty.

(3) #0(SPE)1: The serial spindle module is detected to be abnormal.

Exchange the following module :

8.27

ALARM 750 (SPINDLE

SERIAL LINK

CANNOT BE

STARTED)

Points

Causes

Details of Alarms

Remedies
