POWER MATE MODEL D/F Maintenance manual Page 180

Maintenance manual
B–62835EN/01
4.INTERFACE BETWEEN NC AND PMC
169
(1) Nonvolatile memory control
#7 #6 #5 #4 #3 #2 #1 #0Address
k016
#7(MWRTF2): For checking the writing status in nonvolatile memory
#6(MWRTF1): Writing status in nonvolatile memory
(2) PMC system parameter
The following keep relays are used by the system, therefore they
cannot be used in the sequence program.
#7 #6 #5 #4 #3 #2 #1 #0Address
k017
#5 TRCSTAT
0 : Signal tracing starts by soft key [EXEC] in signal trace
function.
1 : Signal tracing starts automatically by power on in signal
trace function.
#4 MEMINP
0 : Data input cannot be done in memory contents display
function.
1 : Data input can be done in memory contents display
function.
#2 AUTORUN
0 : A sequence program is executed automatically after the
power is turned on.
1 : A sequence program is executed by sequence program soft
key.
#1 PRGRAM
0 : Built–in programmer is not used.
1 : Built–in programmer is used.
#0 LADMASK
0 : Dynamic display of ladder is executed.
1 : Dynamic display of ladder is not executed.
#7 #6 #5 #4 #3 #2 #1 #0Address
k018
#7 #6 #5 #4 #3 #2 #1 #0Address
k019
These bits are used by system. Do not change the values.
Usually all the bits are 0.
