1. DISPLAY AND OPERATION

B–62835EN/01

Classifi-

cation

OperationFunction

key

ModeSETTING

PWE = 1

KEY

Function

Data out-

put to I/O

units

Outputting all the

programs

EDIT PROG

→ –9999 → [ ] → [PUNCH] →

[EXEC]

units

Outputting one

program

EDIT PROG

→ Program No. → [ ] → [PUNCH] →

[EXEC]

Search Searching for a

program number

AUTO or

EDIT

PROG

→ Program No. → [O SRH]

Searching for a

sequence number

AUTO PROG

Program No. search → →

Sequence No. → [N SRH]

Searching for an

address word

EDIT PROG Data to be searched for → [SRH↑ ] or

[SRH ↓]

Searching for an

address only

EDIT PROG Address to be searched for → [SRH↑ ] or

[SRH ↓]

Searching for an

offset number

_ OFFSET Offset No. → [NO.SRH]

Searching for a

diagnosis number

_ SYSTEM

(DGNOS)

Diagnosis No. → [NO.SRH]

Searching for a

parameter number

_ SYSTEM

(PARAM)

Parameter No. → [NO.SRH]

Edit Displaying the

amount of memory

used

EDIT PROG [LIBRARY]

Deleting all the

programs

f EDIT PROG

→ –9999 →

Deleting one program f EDIT PROG

→ Program No. →

Deleting some blocks f EDIT PROG

→ Sequence No. →

Deleting one block f EDIT PROG

→

Deleting a word f EDIT PROG Searching for the word to be deleted

→

Changing a word f EDIT PROG Searching for the word to be changed

→ New data →

Inserting a word f EDIT PROG Searching for the word immediately before

the word to be inserted → New data →

Verify Verifying the memory EDIT PROG [(OPRT)] → [ ] → [READ] → [EXEC]

Input/out-

put with

the PMC

off–line

program-

mer (P–G,

P–G Mate,

personal

computer

FAPT

LADDER)

Ladder program input/

output

– SYSTEM

(PMC)

[ ] → [I/O] →(CHANEL NO)

→ (DEVICE NAME) [HOST] →

[EXEC] →Manipulation on the HOST side

Input/output is discriminated automatically by

manipulation on the HOST side.

Input/

output to/

from the

Searching a file for its

beginning

EDIT PROG

→ FILE No. → [ ] → [F SRH] →

[EXEC]

from

the

FANUC

Cassette

Deleting a file f EDIT PROG

→ FILE No. → [ ] → [F DELETE]

→ [EXEC]

Inputting a program f EDIT PROG

→ FILE No. → [ ] → [READ] →

[EXEC]
