B-63343EN/02 USER PROGRAM 7.PMC CUSTOMIZING TOOLS

- 95 -

7.1 EXTERNAL MENU SIGNALS

In order to select machining type, besides soft-keys menu on screen,

external menu keys on a machine operator's panel can be used. An

operator can select machining type by pushing corresponding menu

keys instead of soft-keys, and these keys can be used only on an initial

screen of MANUAL GUIDE.

1) 16 External Menu Keys for FANUC Standard Machining

Process

PMC DI (Key) Machining Type

R953.0(MT01) Guidance Cutting

R953.1(MT02) Single Cutting

R953.2(MT03) Bar Machining (Rough)

R953.3(MT04) Bar Machining (Finish)

R953.4(MT05) Threading

R953.5(MT06) Grooving (Standard)

R953.6(MT07) Grooving (Trapezoid Rough)

R953.7(MT08) Grooving (Trapezoid Finish)

R954.0(MT09) Center Drilling

R954.1(MT10) Drilling

R954.2(MT11) Reaming

R954.3(MT12) Boring

R954.4(MT13) Tapping

R954.5(MT14) Reserved

R954.6(MT15) Reserved

R954.7(MT16) Reserved

2) 5 External Menu Keys for Custom-made Machining Process

PMC DI (Key) Machining Type

R955.1(EMT1) Custom-made Machining Process (1)

R955.2(EMT2) Custom-made Machining Process (2)

R955.3(EMT3) Custom-made Machining Process (3)

R955.4(EMT4) Custom-made Machining Process (4)

R955.5(EMT5) Custom-made Machining Process (5)

NOTE

If it is necessary to select machining type of

MANUAL GUIDE from ISO programming screen

directly, MTB must make PMC program in which

these external menu signal will be set after

changing to GUIDANCE screen by using 'PD1T'

mentioned later.
