4.DATA STRUCTURE OF MACHINING PROGRAM USER PROGRAM B-63343EN/02

- 38 -

5) C = Displaying window

At the time of C = 0, this data item is displayed in a Process Data

Window in a Program Window, and it will be displayed always

when the corresponding process is selected. The available

maximum number displayed in a Program data as process data is

10.

At the time of C = 1, this data item is displayed in a Pop-up

Window for supplemental process data. This window can be

displayed by pushing soft-key "DETAIL".

At the time of data C=2, this data item is displayed in a Figure

Data Window in a Program Window, and it will be displayed

always when the corresponding process is selected.

CYCLE *** THREAD ***

AREA =

START X =

START Z =

END X =

END Z =

SUPL. DATA 1 =

SUPL. DATA 2 =

Figure Data Window

Process Data Window

Program Window

Pop-up Window

6) +++DEF+ = Displaying character type and color

D = 0: Use Basic Color Palette, and display in normal

character.

= 1: Use Basic Color Palette, and display in reverse

character.

= 2: Use Extended Color Palette for character color E, and

display in normal character.

= 3: Use Extended Color Palette for character color E, and

display in reverse character.

= 4: Use Extended Color Palette for background color F,

and display in normal character.

= 6: Use Extended Color Palette for both character color E

and background color F, and display in normal

character.

= 7: Use Extended Color Palette for both character color E

and background color F, and display in reverse

character

E =Color of Character

= 0: Black (D=0)

Extended Color Palette #8 (D=1, 3, 7)

= 1: Basic Color Palette #1 (D=0, 2, 4, 6)

Extended Color Palette #9 (D=1, 3, 7)

= 2: Basic Color Palette #2 (D=0, 2, 4, 6)

Extended Color Palette #10 (D=1, 3, 7)

= 3: Basic Color Palette #3 (D=0, 2, 4, 6)

Extended Color Palette #11 (D=1, 3, 7)

= 4: Basic Color Palette #4 (D=0, 2, 4, 6)

Extended Color Palette #12 (D=1, 3, 7)
