9.COMMENT ON A MANUAL GUIDE ALL-IN-ONE SCREEN SAMPLE PROGRAM B-63343EN/02

- 484 -

9 COMMENT ON A MANUAL GUIDE ALL-

IN-ONE SCREEN

/* MANUAL GUIDE STRING TABLE PROGRAM

/* O740x COMMENT IN TITLE BAR/STATUS INDICATOR/WARNING and other

/* ******* ENGLISH ********

O7401

/* STATUS INDICATOR STRINGS

/* 12345678901234567890

N1001 ('ACTUAL POSITION'); MAX 20 CHAR STATUS INDICATOR COMMENT (1)

N1002 ('DIST TO GO'); MAX 12 CHAR STATUS INDICATOR COMMENT (2)

N1003 ('NEXT BLOCK'); MAX 12 CHAR STATUS INDICATOR COMMENT (3)

N1004 ('SPINDLE'); MAX 12 CHAR STATUS INDICATOR COMMENT (4)

N1005 ('TOOL'); MAX 06 CHAR STATUS INDICATOR COMMENT (5)

N1006 ('FEEDRATE'); MAX 12 CHAR STATUS INDICATOR COMMENT (6)

N1007 ('MM/MIN'); MAX 06 CHAR STATUS INDICATOR COMMENT (7)

/* 123456789012345678901234567890123456789

N1010 (' PROCESS ');MAX 39 CHAR

/* PROCESS DATA AREA COMMENT(1)

N1020 ('AREA '); MAX 9 CHAR PROCESS DATA AREA COMMENT(2)

N1021 ('TYPE '); MAX 9 CHAR PROCESS DATA ATRA COMMENT(3)

N1025 (' PROGRAM LIST '); MAX 20 CHAR

N1026 (' INPUT '); MAX 10 CHARA

N1027 (' OUTPUT '); MAX 10 CHARA

/* 1234567890123456789012345678901234567890 MAX 40 CHAR

N1030 (' ANIMATED GRAPHIC (EXECUTION) ');

N1031 (' ANIMATED GRAPHIC (SCALE) ');

N1032 (' TOOL PATH GRAPHIC (EXECUTION) ');

N1033 (' TOOL PATH GRAPHIC (SCALE) ');

N1034 (' ALARM ');

/* 123456789012345678901234567890

N1040 ('TOOL FILE ') ; MAX 30 CHAR

N1041 ('TOOL') ; MAX 4 CHAR

N1042 (' NO.') ; MAX 4 CHAR

N1043 (' GEOMETRY ') ; MAX 30 CHAR

N1044 (' WEAR ') ; MAX 30 CHAR

N1045 ('TIP') ; MAX 3 CHAR

N1050 (' PROCESS LIST '); MAX 20 CHAR

N1051 ('PROC'); MAX 4 CHAR PROCESS LIST COMMENT

N1052 ('TYPE'); MAX 4 CHAR PROCESS LIST COMMENT

N1053 ('AREA'); MAX 4 CHAR PROCESS LIST COMMENT

N1054 ('TOOL'); MAX 4 CHAR PROCESS LIST COMMENT

/* 12345678901234567890123456789012345678901234567890

N1060 ('WORK SHIFT MEASURING ') ; MAX 30 CHAR

N1061 ('1.TOOL NUMBER -> INPUT -> TOOL SELECT BUTTON ') ; MAX 48 CHAR

N1062 ('2.TOUCH THE END FACE -> [Z-FACE]') ; MAX 38 CHAR

N1063 ('3.TOUCH THE OUTER SURFACE -> [X-OUTR]') ; MAX 38 CHAR

N1064 ('4.DIAMETER -> INPUT') ; MAX 38 CHAR

N1065 ('5.SHIFT AMOUNT -> INPUT') ; MAX 38 CHAR

N1066 ('WORK SHIFT') ; MAX 10 CHAR
