B-63343EN/02 USER PROGRAM 9.USER POP-UP WINDOW IN AN INITIAL SCREEN

- 133 -

9.3 WATCHING KEY OPERATIONS

1) Custom Macro Variables for watching key operations

In order to watch key operations, the following custom macro

variables can be used.

#8501 : Pushed key identifier excepting numeric keys.

#8503 : Inputted numeric value at INPUT is pushed.

2) Code of pushed key identifier

In order to recognize a pushed key, the following key code are

set in #8501.

Key Code Key Code

Page down 1 Soft-key left 20

Page up 2 Soft-key right 31

Cursor down 3 Soft-key 1 21

Cursor up 4 Soft-key 2 22

Cursor right 18 Soft-key 3 23

Cursor left 19 Soft-key 4 24

ALTER 5 Soft-key 5 25

INSERT 6 Soft-key 6 26

DELETE 7 Soft-key 7 27

INPUT 8 Soft-key 8 28

RESET 10 Soft-key 9 29

NOTE

Soft-key 10 is reserved for [RETURN], and is used

for closing a window and return to an initial screen.

SOFT

KEY1

SOFT

KEY2

SOFT

KEY3

SOFT

KEY4

SOFT

KEY5

SOFT

KEY6

SOFT

KEY7

SOFT

KEY8

SOFT

KEY9

RETURN
