5.USER PROGRAMS FOR MACHINING PROGRAM USER PROGRAM B-63343EN/02

- 84 -

5.1 USER PROGRAMS FOR SETTING DATA FORMAT OF

MACHINING PROCESS DATA

As described in Chapter 4, each data item excepting 'Machining Type'

and 'Machining Area' of whole machining process has its own data

attribute. By using these data attribute, a MANUAL GUIDE system

software displays all data items of machining program.

Program No. Machining Process

O7501 Guidance Cutting

O7502 Single Cutting

O7503 Bar Machining (Roughing)

O7504 Bar Machining (Finishing)

O7505 Threading

O7506 Grooving(Standard)

O7507 Grooving (Roughing of Trapezoidal Groove)

O7508 Grooving (Finishing of Trapezoidal Groove)

O7510 Center Drilling

O7511 Drilling

O7512 Reaming

O7513 Boring

O7514 Tapping

O7515 Custom-made Process (1)

O7516 Custom-made Process (2)

O7517 Custom-made Process (3)

O7518 Custom-made Process (4)

O7519 Custom-made Process (5)

O7521 C-axis Center Drilling

O7522 C-axis Drilling

O7523 C-axis Reaming

O7524 C-axis Boring

O7525 C-axis Tapping

O7526 C-axis Grooving (Roughing)

O7527 C-axis Grooving (Chanfering)

The above custom macro program will be called at each time of

selecting corresponding machining type is selected, and in it, attribute

data for all data items included in the process will be written into

'Data Type' custom macro variables.

In ordinary case, these programs will called once at selecting

machining type initially.
