B-63343EN/02 USER PROGRAM 3.COMMENT ON A MANUAL GUIDE ALL-IN-ONE SCREEN

- 13 -

3.2 COMMENT IN A STATUS INDICATOR WINDOW

ACTUAL POSITION

DIST TO GO

G01 X 0.000

Z 0.000

NEXT BLOCK

G01 X 0.000

Z 0.000

SPINDLE

O01 P01

TOOL

(5)

(4)

(6) (7)

(3)(2)

(1)

FEEDRATE

MM/MIN.

O740n ;

N1001 ( maximum 20ch. ) ;

Alphanumeric letters for comment (1)

N1002 ( maximum 12ch. ) ;

Alphanumeric letters for comment (2)

N1003 ( maximum 12ch. ) ;

Alphanumeric letters for comment (3)

N1004 ( maximum 12ch. ) ;

Alphanumeric letters for comment (4)

N1005 ( maximum 6ch. ) ;

Alphanumeric letters for comment (5)

N1006 ( maximum 6ch. ) ;

Alphanumeric letters for comment (6)

N1007 ( maximum 6ch. ) ;

Alphanumeric letters for comment (7)
