Manual Guide for Lathe Programming manual Page 59

Programming manual

Page of 524

/ 524

B-63343EN/02 USER PROGRAM 4.DATA STRUCTURE OF MACHINING PROGRAM

- 51 -

4.2.6 Threading Process

1) Process data structure

+ 0 System data (Process number) + 30 Multi. Thread type (Data item #13)

+ 1 Reserved + 31 Multi. Thread data (Data item #13)

+ 2 System data + 32 Thread Height type (Data item #14)

+ 3 Machining Type + 33 Thread Height data (Data item #14)

+ 4 Machining Area + 34 Spark Out type (Data item #15)

+ 5 Reserved + 35 Spark Out data (Data item #15)

+ 6 Tool Number type (Data item #1) + 36 Fin. Amnt. type (Data item #16)

+ 7 Tool Number data (Data item #1) + 37 Fin. Amnt. data (Data item #16)

+ 8 Data type #2 (Data item #2) + 38 Clearance X type (Data item #17)

+ 9 Data #2 (Data item #2) + 39 Clearance Z data (Data item #17)

+ 10 Spindle Speed type (Data item #3) + 40 Clearance Z type (Data item #18)

+ 11 Spindle Speed data (Data item #3) + 41 Clearance Z data (Data item #18)

+ 12 Spindle Drct. type (Data item #4) + 42 X Area type (Data item #19)

+ 13 Spindle Drct. data (Data item #4) + 43 X Area data (Data item #19)

+ 14 Start Pos. X type (Data item #5) + 44 Approach X type (Data item #20)

+ 15 Start Pos. X data (Data item #5) + 45 Approach X data (Data item #20)

+ 16 Start Pos. Z type (Data item #5) + 46 Approach Z type (Data item #21)

+ 17 Start Pos. Z data (Data item #5) + 47 Approach Z data (Data item #21)

+ 18 Chamf. on/off type (Data item #6) + 48 Coolant type (Data item #22)

+ 19 Chamf. on/off data (Data item #6) + 49 Coolant data (Data item #22)

+ 20 Cutting Amnt. Type (Data item #8) + 50 Spindle Gear type (Data item #23)

+ 21 Cutting Amnt. data (Data item #8) + 51 Spindle Gear data (Data item #23)

+ 22 Thread Type type (Data item #9) + 52 System data

+ 23 Thread Type data (Data item #9) + 53 System data

+ 24 Cut Method type (Data item #10) + 54 System data

+ 25 Cut method data (Data item #10) + 55 System data (Figure block)

+ 26 Thread Angle type (Data item #11) + 56 System data

+ 27 Thread Angle data (Data item #11) + 57 System data

+ 28 Lead/Thread type (Data item #12) + 58 System data

+ 29 Lead/Thread data (Data item #12) + 59 System data (Next data block)
