B-63343EN/02 USER PROGRAM 3.COMMENT ON A MANUAL GUIDE ALL-IN-ONE SCREEN

- 19 -

3.4.3 Circle (CCW)

CONTR FORM (CIRCLE CCW)

RADIUS R=

CENTER X I=

(1)

(2)

(3)

(4)

(5)

(6)

(7)

END POINT X X=

END POINT Z Z=

CENTER Z K=

OVERRIDE P=

O740n ;

1231 ( maximum 30ch. ) ;

Alphanumeric letters for comment (1)

N1232 ( maximum 18ch. ) ;

Alphanumeric letters for comment (2)

N1233 ( maximum 18ch. ) ;

Alphanumeric letters for comment (3)

N1234 ( maximum 18ch. ) ;

Alphanumeric letters for comment (4)

N1235 ( maximum 18ch. ) ;

Alphanumeric letters for comment (5)

N1236 ( maximum 18ch. ) ;

Alphanumeric letters for comment (6)

N1237 ( maximum 18ch. ) ;

Alphanumeric letters for comment (7)
