B-63343EN/02 USER PROGRAM 5.USER PROGRAMS FOR MACHINING PROGRAM

- 85 -

5.2 USER PROGRAMS FOR DISPLAYING GUIDANCE

WINDOW

For each data items of machining program, Guidance Window, a kind

of Pop-up Window, can be displayed for explanation.

Program No. Machining Process

O7551 Guidance Cutting

O7552 Single Cutting

O7553 Bar Machining (Roughing)

O7554 Bar Machining (Finishing)

O7555 Threading

O7556 Grooving (Standard)

O7557 Grooving (Roughing of Trapezoidal Groove)

O7558 Grooving (Finishing of Trapezoidal Groove)

O7560 Center Drilling

O7561 Drilling

O7562 Reaming

O7563 Boring

O7564 Tapping

O7565 Custom-made Process (1)

O7566 Custom-made Process (2)

O7567 Custom-made Process (3)

O7568 Custom-made Process (4)

O7569 Custom-made Process (5)

O7571 C-axis Center Drilling

O7572 C-axis Drilling

O7573 C-axis Reaming

O7574 C-axis Boring

O7575 C-axis Tapping

O7576 C-axis Grooving (Roughing)

O7577 C-axis Grooving (Chanfering)

The above custom macro program will be called once at displaying a

process data window initially, selecting a process at the first time or

displaying the already made process for editing. Further more, at

pushing a [WIN ON] to display a guidance window, this program will

be called.

A pop-up window is automatically opened, and its position and size

are fixed and cannot be changed.

If a custom macro program of the above is not registered, the

corresponding guidance window is not opened.
