Manual Guide for Lathe Programming manual Page 136

Programming manual

Page of 524

/ 524

8.COMMENT OF SOFT-KEYS IN ALL-IN-ONE SCREEN USER PROGRAM B-63343EN/02

- 128 -

5) Comment table program for soft-key menu

O712n ;

1201 ( maximum 18ch. ) ;

Alphanumeric letters for "LINE" in Bar Roughing

and Finishing

N1202 ( maximum 18ch. ) ;

Alphanumeric letters for "CW" in Bar Roughing

and Finishing

N1203 ( maximum 18ch. ) ;

Alphanumeric letters for "CCWLINE" in Bar

Roughing and Finishing

N1204 ( maximum 18ch. ) ;

Alphanumeric letters for "ROUND" in Bar

Roughing and Finishing

N1205 ( maximum 18ch. ) ;

Alphanumeric letters for "CHAMF" in Bar

Roughing and Finishing

N1206 ( maximum 18ch. ) ;

Alphanumeric letters for "TANGNT" in Bar

Roughing and Finishing

N1210 ( maximum 18ch. ) ;

Alphanumeric letters for "CALC" in Bar Roughing

and Finishing

N1215 ( maximum 18ch. ) ;

Alphanumeric letters for "CAN" in Bar Roughing

and Finishing

N1231 ( maximum 18ch. ) ;

Alphanumeric letters for "+10" in Bar Roughing

and Finishing

N1232 ( maximum 18ch. ) ;

Alphanumeric letters for "-10" in Bar Roughing and

Finishing
