5.USER PROGRAMS FOR MACHINING PROGRAM USER PROGRAM B-63343EN/02

- 86 -

Program No. Machining Process

O7601 Guidance Cutting

O7602 Single Cutting

O7603 Bar Machining (Roughing)

O7604 Bar Machining (Finishing)

O7605 Threading

O7606 Grooving (Standard)

O7607 Grooving (Roughing of Trapezoidal Groove)

O7608 Grooving (Finishing of Trapezoidal Groove)

O7610 Center Drilling

O7611 Drilling

O7612 Reaming

O7613 Boring

O7614 Tapping

O7615 Custom-made Process (1)

O7616 Custom-made Process (2)

O7617 Custom-made Process (3)

O7618 Custom-made Process (4)

O7619 Custom-made Process (5)

O7521 C-axis Center Drilling

O7522 C-axis Drilling

O7523 C-axis Reaming

O7524 C-axis Boring

O7525 C-axis Tapping

O7526 C-axis Grooving (Roughing)

O7527 C-axis Grooving (Chanfering)

The above custom macro program will be called every cycle during

the guidance window is opened. In it, by watching the cursor moving

to some data item, the corresponding guidance drawing can be

displayed for each data items.

1) System macro variables for cursor position

In order to display a proper Guidance Window for each data item,

by reading the following system custom macro variables, User

Program can know the contents of the active data items.

#9200 :Data item number of the active one, a cursor is pointed.

Machining Type = 50

Machining Area = 60

Figure data of other Bar machining = 100 + Number of

Figure Data Item #

Figure data of Bar machining = 100

Other Data Items = Number of Data Item #
