B-63343EN/02 USER PROGRAM 4.DATA STRUCTURE OF MACHINING PROGRAM

- 63 -

4.2.12 Drilling Process

1) Process data structure

+ 0 System data (Process number) + 30 Depth Dcrs. type (Data item #13)

+ 1 Machining type (2) + 31 Depth Dcrs. data (Data item #13)

+ 2 System data + 32 Return Amnt. type (Data item #14)

+ 3 Machining Type + 33 Return Amnt. data (Data item #14)

+ 4 Reserved + 34 Min. Depth type (Data item #15)

+ 5 Reserved + 35 Min. Depth data (Data item #15)

+ 6 Tool Number type (Data item #1) + 36 Start Feed type (Data item #16)

+ 7 Tool Number data (Data item #1) + 37 Start Feed data (Data item #16)

+ 8 Feedrate type (Data item #2) + 38 Start Clr. type (Data item #17)

+ 9 Feedrate data (Data item #2) + 39 Start Clr. data (Data item #17)

+ 10 Spindle Speed type (Data item #3) + 40 Data type #18 (Data item #18)

+ 11 Spindle Speed data (Data item #3) + 41 Data #18 (Data item #18)

+ 12 Spindle Drct. type (Data item #4) + 42 Data type #19 (Data item #19)

+ 13 Spindle Drct. data (Data item #4) + 43 Data #19 (Data item #19)

+ 14 Start Pos. X type (Data item #5) + 44 Approach X type (Data item #20)

+ 15 Start Pos. X data (Data item #5) + 45 Approach X data (Data item #20)

+ 16 Start Pos. Z type (Data item #6) + 46 Approach Z type (Data item #21)

+ 17 Start Pos. Z data (Data item #6) + 47 Approach Z data (Data item #21)

+ 18 Hole Diameter type (Data item #7) + 48 Coolant type (Data item #22)

+ 19 Hole Diameter data (Data item #7) + 49 Coolant data (Data item #22)

+ 20 Hole Start Z type (Data item #8) + 50 Spindle Gear type (Data item #23)

+ 21 Hole Start Z data (Data item #8) + 51 Spindle Gear data (Data item #23)

+ 22 Depth/End Z type (Data item #9) + 52 System data

+ 23 Depth/End Z data (Data item #9) + 53 System data

+ 24 Infeed Amount type (Data item#10) + 54 System data

+ 25 Infeed Amount data (Data item#10) + 55 System data (Figure block)

+ 26 Dwell Timer type (Data item #11) + 56 System data

+ 27 Dwell Timer data (Data item #11) + 57 System data

+ 28 Cut Pattern type (Data item #12) + 58 System data

+ 29 Cut Pattern data (Data item #12) + 59 System data (Next data block)
