3.COMMENT ON A MANUAL GUIDE ALL-IN-ONE SCREEN USER PROGRAM B-63343EN/02

- 30 -

3.8 WARNING MESSAGES

In MANUAL GUIDE, various warning message on operations and

inputted data are displayed. These messages are set in the comment

table program as follows, and can be modified by M.T.B.

O740n ;

6001 ( maximum 38ch. ) ;

Alphanumeric letters for "0200 Program No. has already

been used"

N6002 ( maximum 38ch. ) ;

Alphanumeric letters for "0203 Number of programs is

exceeded"

N6003 ( maximum 38ch. ) ;

Alphanumeric letters for "0204 Number of process is

exceeded"

N6004 ( maximum 38ch. ) ;

Alphanumeric letters for "0202 The program No.

cannot be searched"

N6005 ( maximum 38ch. ) ;

Alphanumeric letters for "0000 System error"

N6006 ( maximum 38ch. ) ;

Alphanumeric letters for "0201 Input data cannot be

allowed"

N6007 ( maximum 38ch. ) ;

Alphanumeric letters for "0206 Number of process is

exceeded"

N6008 ( maximum 38ch. ) ;

Alphanumeric letters for "0207 Next process cannot be

found"

N6009 ( maximum 38ch. ) ;

Alphanumeric letters for "0800 Input data is incorrect"

N6010 ( maximum 38ch. ) ;

Alphanumeric letters for "0801 Number of blocks

exceed 30 block"
