B-63343EN/02 USER PROGRAM 8.COMMENT OF SOFT-KEYS IN ALL-IN-ONE SCREEN

- 121 -

8.6 GUIDANCE CUTTING PROCESS

In case of guidance cutting process being done, following soft-keys

are displayed as occasion demand.

1) Soft-key group #1 displayed before selecting a guidance cutting

of line or circle

LINE CIRCLE AUX RAPID CUT

LINE : Select a guidance cutting of line

CIRCLE : Select a guidance cutting of circle

AUX : Teach-in an auxiliary function block

RAPID : Teach-in a rapid traverse block

CUT: Teach-in a cutting block

2) Soft-key group #2 for inputting data and carrying out a guidance

cutting of line or circle

RD POS. LMT ON AUX RAPID CUT INPEND

RD POS. : Read an actual tool position and set into a current

position data

LMT ON : Select a limit cutting mode

LMTOFF : Cancel a limit cutting mode

NOTE

Soft-key [LMT ON] and [LMT OFF] are replaced

each other by pushing it.

AUX : Teach-in an auxiliary function block

RAPID : Teach-in a rapid traverse block

CUT : Teach-in a cutting block

INPEND : Conclude inputting data of target line or circle, and

begin guidance cutting using guidance handwheel,

and this changed to [GD END].
