B-63343EN/02 USER PROGRAM 3.COMMENT ON A MANUAL GUIDE ALL-IN-ONE SCREEN
- 17 -
3.4 COMMENT IN A CONTOUR INPUTTING WINDOWS
In Bar machining cycle, free form made up with line and circle can be
inputted by using Contour Inputting Windows. Contents of data items
displayed in them are cannot be changed, but comment for them can
be modified as follows.
3.4.1 Line
CONTR FORM (LINE)
END POINT X X=
END POINT Z Z=
ANGLE A=
OVERRIDE P=
(1)
(2)
(3)
(4)
(5)
O740n ;
1211 ( maximum 30ch. ) ;
Alphanumeric letters for comment (1)
N1212 ( maximum 18ch. ) ;
Alphanumeric letters for comment (2)
N1213 ( maximum 18ch. ) ;
Alphanumeric letters for comment (3)
N1214 ( maximum 18ch. ) ;
Alphanumeric letters for comment (4)
N1215 ( maximum 18ch. ) ;
Alphanumeric letters for comment (5)
