B-63343EN/02 USER PROGRAM 8.COMMENT OF SOFT-KEYS IN ALL-IN-ONE SCREEN

- 115 -

8.5 PROGRAM LIST WINDOW

At the time of displaying a program list window, following soft-keys

used for carrying out a necessary operation are displayed.

PATH ANIMAT ANIMAT CNVNC EDIT COPY RETURN EXEC

By pushing a soft-key [+], the following soft-keys are displayed.

ALL-PN PUNCH READ

PATH : Select a program for tool path drawing simulation

ANIMAT : Select a program for animated drawing with solid

model

ANIMAT : Select a program for animated drawing with tool path

drawing

CNVNC : Select a program for NC format program conversion

EDIT : Select a program for editing

COPY : Copy a program

RETURN : Close a program list window

EXEC : Start actual machining program performing

ALL-PN : Punch out all programs

PUNCH : Punch out a program directed by cursor

READ : READ a program from external device

1) Soft-keys used for Tool Path Drawing Simulation

SPD UP SPD DW PLOT HEAD PROCES EXEC SINGLE

SPD UP : Increase the simulation speed

SPD DW : Reduce the simulation speed

PLOT : Display inputted figure on a workpiece

HEAD : Initialize a graphic window, and return to top of a

program

PROCES : Begin a tool path drawing simulation of the active

process only

EXEC : Begin a tool path drawing simulation of all processes

of a program

SINGLE : Select a single block simulation mode
