B-63343EN/02 USER PROGRAM 4.DATA STRUCTURE OF MACHINING PROGRAM

- 41 -

4.2 DETAILS OF DATA STRUCTURE FOR EACH MACHINING

TYPE

4.2.1 Initial Setting Block

This data block is automatically allocated at the top of each

machining program, and includes common data used for each

program.

+ 0 Reserved + 30 Reserved

+ 1 Workpiece figure (1 = bar, 2 = molding material) + 31 Reserved

+ 2 Outer diameter of workpiece + 32 Reserved

+ 3 Inner diameter of workpiece + 33 Reserved

+ 4 Length of workpiece + 34 Reserved

+ 5 Not used + 35 Reserved

+ 6 Not used + 36 Reserved

+ 7 Reserved + 37 Reserved

+ 8 Reserved + 38 Reserved

+ 9 Reserved + 39

+ 10 Reserved + 40 Program name

+ 11 Reserved + 41 (ASCII code)

+ 12 Reserved + 42

+ 13 Reserved + 43

+ 14 Reserved + 44 Not used

+ 15 Reserved + 45 Not used

+ 16 Reserved + 46 Not used

+ 17 Reserved + 47 System data

+ 18 Reserved + 48 Running time

+ 19 Reserved + 49 Reserved

+ 20 Reserved + 50 Reserved

+ 21 Reserved + 51 Reserved

+ 22 Reserved + 52 Reserved

+ 23 Reserved + 53 Not used

+ 24 Reserved + 54 Not used

+ 25 Program updated date (y/m/d) + 55 System data (Molding material figure block)

+ 26 Program updated time (h/m) + 56 System data

+ 27 Reserved + 57 System data

+ 28 Reserved + 58 System data

+ 29 Reserved + 59 System data (Next data block)

CAUTION

"Reserved" and "System data" must be never

changed by any means.
