B--65245EN/02

2. REPLACING FAN MOTOR

MAINTENANCE OF

SERVO AMPLIFIER UNIT

159

CAUTION

When the servo amplifier unit is used in an absolute system,

check the reference position return procedure before

replacing the fan. During fan replacement, the reference

position is lost by removing the CX5X battery connector and

the JF1 connector.

If the battery is shared, the reference position return

procedure must be checked o n a ll the units sharing it.

1. Have a replacement fun on hand.

2. Remove all the connect ors connected to the servo amplifier unit.

Check that the connectors have marks such as connector numbers on

them, so that the connectors can be re--connected correctly.

3. If the battery cover is located at the bottom of the servo amplifier unit,

grasp the right and left sides of the battery cover, and pull i t out.

4. Release the latches located at the top and bottom of t he plastic cover

of the servo amplifier unit, and remove the plastic cover toward you.

5. Remove the fan cable from the C NF N1 connector. Then, remove the

two screws securing the fan to remove the fan.

6. Secure the new fan with the screws and connect the cable to the

CNFN1 connector.

7. Put back the plastic cover.

8. With the battery installed, mount the battery cover to the servo

amplifier unit.

9. Put back the other cables correctly.

10.Turn the power on and establish t he reference position. This completes

the replacement of the fan.

Use Specifications Quantity

Replacement fan A06B --6093--K101 1

2.1

FOR SERVO

AMPLIFIER UNITS OF

THE 12A AND 20A

TYPES
