FANUC SERVO MOTOR BETA series I/O
Link Option Add function in edition 09
B-65245EN/02-01
7. Improvement of turret and magazine number, point number output
7.1.
7.1.7.1.
7.1.
Outline
Outline Outline
Outline
In conventional specifications of the ATC/Turret control (function code 02) and the point
positioning control (function code 03) in the peripheral equipment control, when ATC number
or point number is selected by the parameter (parameter No.020=1) as response data, the
turret and magazine number or the point number is not output until the reference position is
established. This specifications has been improved. When the parameter No.007#2(NZRPO) is
set to “1”, the turret and magazine number or the point number is output even if the reference
point is not established. But when the parameter No.007#2(NZRPO) is set to “0”, the
specifications is as before.
7.2.
7.2.7.2.
7.2.
Parameter
Parameter Parameter
Parameter
No #7 #6 #5 #4 #3 #2 #1 #0
007 NZRPO
Size
SizeSize
Size : 1 byte (bit type)
Standard value
Standard valueStandard value
Standard value : 0
NZRPO
NZRPONZRPO
NZRPOIn case that the reference position is not established, when ATC/Turret
control or point positioning control is executed, the turret and
magazine number or the point number is
0 : Not output
1 : Output
NOTE
This parameter is valid when the parameter No.020 is set to “1”.
