Servo Motor Beta Series (I/O Link Option) Maintenance manual Page 281

Maintenance manual
B-65245EN/02-02
5/5
EDIT
DATE DESIG.
DESCRIPTION
FANUC SERVO MOTOR β series I/O Link Option
Skip Function
TITLE
DRAW.NO. CUST.
SHEET
01
02.05.06
Newly added
FEED RATE: 1 ~ 65535 (user unit*10**N/min.)
N is set with parameter No.21.
DISTANCE (ABSOLUTE POSITION): -99999999 ~ 99999999 (user unit)
NMOD =1: Execution completion notification mode
(For details, see Section 4.2.)
RPD=1: Raid traverse
SKIP=1: Skip function effective
If SKIP is set to 1, moving command is interrupted immediately when a skip
signal (HDI) is input while the moving command is being executed. In case
automatic operation by using 32 buffering blocks is executed, the current block is
skipped and the next block is started.
The work coordinate where a skip signal is input is recorded. The host can read
this value by the direct command (reading out measuring data by skip function.
Function code=0x32)
#7 #6 #5 #4 #3 #2 #1 #0
Yy+4 Control flag 1
Yy+5 0 1 0 1 0 0 0 1
(0x61)
Yy+6 0 0 0 0 NMOD 0 0 1
Yy+7 SKIP RPD 0 0 0 0 0 1
Yy+8 FEED RATE
Yy+9
Yy+10
Yy+11
DISTANCE
Yy+12
Yy+13
Please replace the instruction command format in the subsection 4.4.4 Axis Movement
Commands (2) Absolute positioning of II HANDLING 4. DIRECT COMMANDS
with the
following. (The explanation and “SKIP” are added.)
