Servo Motor Beta Series (I/O Link Option) Maintenance manual Page 267

Maintenance manual
Edit.
4/13
Date Signature Change
FANUC SERVO MOTOR BETA series I/O
Link Option Add function in edition 09
B-65245EN/02-01
No
066 F1 rate for rapid traverse override
Size
SizeSize
Size : 2 bytes
Unit
UnitUnit
Unit : 10
N
user-specified units/MIN
Range
RangeRange
Range : 1 to 65535 (7500 user-specified units/MIN or greater)
Standard value
Standard valueStandard value
Standard value : 10
Description
DescriptionDescription
Description : Specifies the F1 rate for rapid traverse override. (N is specified in
parameter No.21.)
NOTE
This parameter is valid when the parameter No.002#6 (RVF2) is set to “1”.
No
067 F2 rate for rapid traverse override
Size
SizeSize
Size : 2 bytes
Unit
UnitUnit
Unit : 10
N
user-specified units/MIN
Range
RangeRange
Range : 1 to 65535 (7500 user-specified units/MIN or greater)
Standard value
Standard valueStandard value
Standard value : 10
Description
DescriptionDescription
Description : Specifies the F2 rate for rapid traverse override. (N is specified in
parameter No.21.)
NOTE
This parameter is valid when the parameter No.002#6 (RVF2) is set to “1”.
