2. SIGNAL DESCRIPTIONSHANDLING
57
[Operation]
The servo amplifier unit exclusive--ORs ABSWT with ABSRD.
When the result of exclusive--OR is 0, response data (Xx+3 to Xx+6)
is written, and this signal i s inverted.
(8) Response data read completion signal ABSRD
[Classification]
Output signal <Yy+1#4>
[Function]
After reading response data (Xx+3 to Xx+6), the host inverts this
signal for notification to the servo amplifier unit.
[Operation]
The host exclusive--OR s ABSWT with ABSRD. When the result of
exclusive--OR is 1, response data (Xx+3 to Xx+6) is read, and this
signal is inverted.
(9) Alarm output command signal DSAL
[Classification]
Output signal <Yy+0#3>
[Function]
The host specifies that alarm information be output as response data.
When DSAL is 1, the following information is output as response
data.
Xx+4, Xx+5
Xx+3
Number of alarms (byte type)
Alarm number (word type)
[Operation]
When the signal is 0, a turret, magazine, point number, coordinates,
or motor current value are output as response data. When the signal
is 1, the number of alarms and the first alarm number are output as
response data.
(10) Alarm output state check signal DSALO
[Classification]
Input signal <Xx+2#3>
[Function]
The servo amplifier unit indicates the contents of the response data.
[Input condition]
Whe n the signal is 0, a turret, magazine, point number , coordinate s, or
motor curre nt value are being output as response data. When the signal
is 1, the number of alarms and the first alarm number are being output
as response data.
(1) Function code command strobe signal EBUF
[Classification]
Output signal <Yy+4#7>
[Function]
After setting the function code (Yy+5) and command data (Yy+6 t o
Yy+15), the host inverts the logical state of this signal to indicate to
the servo amplifier unit that the function code is ready for transfer.
