Servo Motor Beta Series (I/O Link Option) Maintenance manual Page 312

Maintenance manual

Page of 317

/ 317

B-65245EN/02-8

8/11

EDIT

DATE DESIG.

DESCRIPTION

FANUC SERVO MOTOR β series I/O Link Option

Skip Function (Improvement of the specification) and

CAUTION to the parameters No.068, 141

TITLE

DRAW.NO. CUST.

SHEET

04.05.06

Newly added

FEED RATE:1～65535 (user unit*10**N/min.)

N is set with parameter No.21.

DISTANCE(INCREMENTAL POSITION):-99999999～99999999(user unit)

NMOD =1: Execution completion notification mode

(For details, see Section 4.2.)

RPD=1: Raid traverse

SKIP=1: Skip function effective

If SKIP is set to 1, moving command is interrupted immediately when a skip signal

(HDI) is input while the moving command is being executed. In case automatic

operation by using 32 buffering blocks is executed, the current block is skipped

and the next block is started.

The work coordinate where a skip signal is input is recorded. The host can read

this value by the direct command (reading out measuring data by skip function.

Function code=0x32)

Please replace the instruction command format in the subsection 4.4.4 Axis Movement

Commands (3) Incremental positioning of II HANDLING 4. DIRECT COMMANDS with the

following. (The explanation and “SKIP” are added.)

#7 #6 #5 #4 #3 #2 #1 #0

Yy+4 Control flag 1

Yy+5 0 1 1 0 0 0 1 0

(0x62)

Yy+6 0 0 0 0 NMOD 0 0 1

Yy+7 SKIP RPD 0 0 0 0 0 1

Yy+8 FEED RATE

Yy+9

Yy+10

Yy+11 DISTANCE

Yy+12

Yy+13

NOTE

1. When the axis arrives to the end point without the skip signal (HDI) input in the skip function,

the kind of registered position can be selected by the parameter No.17#2 (SPCO)

setting.(0:Register the before skip position. 1:Register the commanded end position).

2. When the skip function is operated, if the axis moving is stopped by the Emergency stop,

reset, alarm, the registered position is not refreshed.
