B–63294EN/02

2. MACHINING MENU DESCRIPTIONS

– 158 –

3) Example of program

It is used only for one machining menu with a series of processes like the figure below when the multiple

parts are made from a single sheet. In this case, only the track pocket is made using several menu copies

(Pattern).

1. The data is input selecting the initial setting screen first.

2. The machining menu is selected one by one.

3. ”Pocketing Prep”, ”Menu Copy” (Pattern), then ”Track” are selected in turn for multiple copy from a

single sheet when pocketing.

4. The programming ends by selecting ”end of program”.

Program contents

ZI01 (Initial setting) Q_M_I···;

ZF01 (Facing prepare) YB_Z_U···;

ZF02 (Square UNI–DIR) X_Y_U···;

ZE99 (End of machining);

ZP01 (Pocketing/grooving) YB_R_Z···;

ZP10 (Copy pattern) YA_B_E···;

ZP04 (Track pocket) YA_X_Y···;

ZE99 (End of machining);

ZH01 (Drilling) YB_B_V···;

ZL02 (Line (same space)) X_Y_E···;

ZE99 (End of machining);

ZI02 (End of program) C_T_;

Square facing

Track pocketing

Hole machining

4) Notes

It is impossible to use Copy (random) and Copy (pattern) simultaneously in the same machining menu.
