SUPER CAPi M Operators manual Page 421

Operators manual

Page of 462

/ 462

B–63294EN/02

2. MACHINING MENU DESCRIPTIONS

– 411 –

4. Limitations

D Restart

Under any of the following conditions, restart cannot be performed:

S When automatic operation has not been performed since the power was turned on

S When automatic operation has not been performed since an emergency stop was released

S When automatic operation has not been performed since the coordinate system was changed or

shifted (change in an external offset from the workpiece reference point)

D Restart Block

The block to be restarted need not be the block which was interrupted;

operation can restart with any block. But the restart block must use the same coordinate system as

when operation was interrupted.

D Single block

When single block operation is ON during movement to the restart position, operation stops every time

the tool completes movement along axes. When operation is stopped in the single block mode, MDI

intervention cannot be performed.

D Manual intervention

During movement to the restart position, manual intervention can be used to perform a return opera-

tion for axis if it has not yet been performed for the axis. A return operation cannot be done further on

axes for which a return has already been completed. And move command cannot be specified from

the MDI panel during a restart operation.

D Reset

Never reset during the time from the start of a search at restart until machining is restarted. Otherwise,

restart must be performed again from the first step.

D Manual absolute

Regardless of whether machining has started or not, manual operation must be performed when the

manual absolute mode is on.

D Reference position return

If no absolute–position detector (absolute pulse coder) is provided, be sure to

perform reference position return after turning on the power and before performing restart.

D Moving the axis on MDI mode after searching the block number

After searching the block number, it is impossible to move the axis on MDI mode such like “Macro Call

Command” with M/T/G–code or “Axis Control by PMC” function. It is possible to move the axis with

manual handle or Jog operation only.

If the operator wants to move the axis on MDI mode, please move it before searching the block number

surely.

Be sure to set the following parameter No. 3407.

#7 #6 #5 #4 #3 #2 #1 #0

3407 C14

By resetting on the CRT/MDI panel, the G code of group number 14 is:

C14 = 0 : Cleared.

= 1 : Not cleared.

Be sure to set 1.
