SUPER CAPi M Operators manual Page 42

Operators manual
B–63294EN/021. OVERVIEW OF Super CAPi M
– 32 –
1.3.2 Insert function
The insert function inserts a new machining process between machining processes or adds it after a machining
process.
1. Place the cursor on the process after which a new process is to be added. For example, move the cursor
to a facing process.
DELETECOPYMOVE<
PROGRAM O1234 PAGE :01/ EDITING
NO. CYCLE PROCESS TOOL NAME TOOL NO N–DIA FEED SPINDL
INSERTALTER
001 AUXILIARY INITAL SETING
002 FACING FACING PREP. FACE MILL 72. 40.000 773. 1431.
FACING PREP. FACE MILL 73. 50.000 309. 572.
FACING SQUARE BIDIR
PROCESS END
003 HOLE TAPPING CENTER DRILL 3. 3.000 42. 4240.
TAPPING DRILL 12. 4.000 50. 5000.
TAPPING DRILL 14. 8.000 318. 3180.
TAPPING TAP 25. 10.000 280. 254.
HOLE PATERN PARALLELOGRM
PROCESS END
004 AUXILIARY END OF PROG.
2. Press the soft key [INSERT]. Processes that can be inserted are automatically selected according to the
position of the cursor. When the cursor is placed on INITAL SETING or PROCESS END as shown above,
any machining menu can be inserted. When the cursor is placed on the start menu or figure menu of a
machining menu, only the figure menu of the corresponding machining can be inserted.
SELECT SOFTKEY.
NC LAN
GUAGE
POCKET
TING
SIDE C
UTING
FACINGHOLE< PROGRM
END
AUXILI
ARY
PROGRAM O1234 PAGE :01/ EDITING
NO. CYCLE PROCESS TOOL NAME TOOL NO N–DIA FEED SPINDL
2+1/2
CCV
2+1/2
CVX
001 AUXILIARY INITAL SETING
002 FACING FACING PREP. FACE MILL 72. 40.000 773. 1431.
FACING PREP. FACE MILL 73. 50.000 309. 572.
FACING SQUARE BIDIR
PROCESS END
003 HOLE TAPPING CENTER DRILL 3. 3.000 42. 4240.
TAPPING DRILL 12. 4.000 50. 5000.
TAPPING DRILL 14. 8.000 318. 3180.
TAPPING TAP 25. 10.000 280. 254.
HOLE PATERN PARALLELOGRM
PROCESS END
004 AUXILIARY END OF PROG.
