SUPER CAPi M Operators manual Page 57

Operators manual
B–63294EN/02 1. OVERVIEW OF Super CAPi M
– 47 –
When optimal process editing is applied to a program including any of these processes and NC
statements, the partial range setting capability of the optimal process editing function must be
used. After checking for any processes whose execution timing must not be changed, the oper-
ator can then apply optimal process editing to processes whose sequences may be rearranged.
Similarly, be careful not to change the sequence of machining menus that cannot be reversed.
Set a partial range for this section.
Rotation around the B axis
⋅
⋅
⋅
Set another partial range for this section.
Drilling Drill 1
Drill 2
Hole position A
Process end
Drilling Drill 1
Drill 3
Hole position B
Process end
Drilling Drill 1
Drill 3
Hole position B
Process end
NOTE 2 The complete range setting can be used on programs for which the sequence of machining me-
nus can be reversed.
NOTE 3 When the system determines that optimization is impossible (for example, when a process for
rotation about the B axis is included in a partial setting range), the system does not perform opti-
mal process editing, but instead outputs the alarm message NOT SUITABLE COMBINE PRO-
GRAM.
