E. DISPLAYING AND SETTING
PARAMETERS
B–63443EN/02
APPENDIX
274
Procedure for displaying and setting parameters
1 Set 1 for PARAMETER WRITE to enable writing. See the procedure
for enabling/disabling parameter writing described below.
2 Press function key
SYSTEM
.
3 Press chapter selection soft key
[PARAM] to display the parameter
screen.
PARAMETER (SETTING) O0010 N00002
0000 SEQ INI ISO TVC
0 0 0 0 0 0 0 0
0001
0 0 0 0 0 0 0 0
0012 MIR
X 0 0 0 0 0 0 0 0
Y 0 0 0 0 0 0 0 0
0020 I/O CHANNEL
> _
MDI **** *** ***
[ PARAM ][ DGNOS ][ PMC ][ SYSTEM ][ (OPRT) ]
4 Move the cursor to the parameter number to be set or displayed in
either of the following ways:
⋅ Enter the parameter number and press soft key
[NO.SRH] .
⋅ Move the cursor to the parameter number using the page keys,
PAGE
and
PAGE
, and cursor keys, , , , and .
5 To set the parameter, enter a new value with numeric keys and press
soft key
[INPUT]. The parameter is set to the entered value and the
value is displayed.
6 Set 0 for
PARAMETER WRITE to disable writing.
Press the <DGNOS/PARAM> key to toggle between the parameter
screen, diagnostic screen, and pitch error compensation data screen.
>&0001 01010101
&0002 01010101
Parameter screen Diagnostic screen
>@0800 0
@0801 0
Display of PMC data
>D0000 00000000
D0001 00000000
Key operation
âã
Pitch error compensation data screen
>P000 1
P001 0
Procedure for CRT/MDI
Procedure for DPL/MDI
