Series 16i/160i/160is/18i/180i/180is/ Maintenance manual Page 437

Maintenance manual
B–63525EN/02
6. INPUT AND OUTPUT OF DATA
407
7)
0103 Baud rate
1: 50 5: 200 9: 2400
2: 100 6: 300 l10: 4800
3: 110 7: 600 11: 9600
4: 150 8: 1200 12: 19200 [BPS]
3. Press soft key [(OPRT)] and soft key
4. Press soft key [READ] and [EXEC]. Then input of parameters are
started.
5. Because alarm 300 will generate for the system with absolute pulse
coder, set parameter 1815#5 to 0.
6. Alarm 300 is issued if the system employs an absolute pulse coder.
In such a case, perform reference position return again.
Set the emergency stop state.
Operation of 12 is not required when PPR is used.
1. Turn off (KEY4=1) the program protect key.
2. Press
OFFSET
SETTING
key and soft key [SETTING] to select the SETTING
screen.
3. Confirm that PARAMETER WRITE=1.
4. Press
SYSTEM
key and soft key [PMC].
5. Press soft key [PMCPRM] and soft key [KEEPRL].
6. Set the cursor to K17 and set bit 1 to 1.
0 0 0 0 0 0
1
0
INPUT
.
7. Press
key and key.
8. Press soft key [I/O] and set the parameters required for I/O.
Item selection cursor displays the next item after an item is set.
9. In CHANNEL item , press
1
INPUT
to select channel 1.
10.In DEVICE item, press [FDCAS] key to select the floppy cassette.
11.In FUNCTION item, press soft key [READ] to input data
12.In FILE NO item, press
2
INPUT
to select file no. 2.
13.Press soft key [EXECT] and the PMC parameters are started to be
input.
14.After data has been read, turn off power and turn it on.
6.2.9
Inputting PMC
Parameters
