Series 16i/160i/160is/18i/180i/180is/ Maintenance manual Page 487

Maintenance manual
B–63525EN/02
7.INTERFACE BETWEEN CNC AND PMC
457
PMC–SA1 screen menu selection procedure
[PMC] [PMCLAD] Ladder diagram display screen
[PMCDGN] [TITLE] Title screen
[STATUS] Signal status screen
[ALARM] Alarm screen
[TRACE] Trace function
[IOCHK] I/O check screen
[PMCPRM] [TIMER] Timer screen
[COUNTR] Counter screen
[KEEPRL] Keep relay screen
[DATA] [G.DATA] Data table screen
[SETING] Setting screen
[RUN]/[STOP] Ladder start/stop
[EDIT] [TITLE] Title editing screen
[LADDER] Ladder diagram editing screen
[SYMBOL] Symbol/comment editing screen
[MESAGE] Message editing screen
[MODULE] I/O unit address setting screen
[CROSS] Cross reference screen
[CLEAR] Clear screen
[I/O] Program/parameter input/output screen
[SYSPRM] System parameter screen
[MONIT] [ONLINE] Online setting screen
7.3
PMC SCREEN
7.3.1
PMC Menu Selection
Procedure Using Soft
Keys
