Series 16i/160i/160is/18i/180i/180is/ Maintenance manual Page 449

Maintenance manual
B–63525EN/02
6. INPUT AND OUTPUT OF DATA
419
Symbol CAPi T data is stored in the sub–memory (SRAM) on the symbol
CAPi T board. When replacing the symbol CAPi T board, perform data
input/output operation according to this section.
1. System parameter (FAPT–SYS. PARAM.)
2. MTF (FAPT–MTF)
3. Setting data (FAPT–SETTING)
4. Tool data (FAPT–TOOL)
5. Graphic data (FAPT–GRAPHIC)
6. Files
Family program (FAPT–FAMILY)
Material file (FAPT–MATERIAL)
Tooling information (FAPT–TOOL)
Sub cycle file (FAPT–SUB. CYCLE)
1. Display the screen of Symbolic FAPT TURN.
2. To output data on FANUC Cassette, press keys as follows:
[AUXILIARY]⇒
D U M P
,
B
INPUT
Be careful that data is memorized from top of the file.
To output data on FANUC PPR, press keys as follows:
[AUXILIARY]⇒
D U M P
,
P
INPUT
1. Hold
SP
key and turn on power.
2. To input data from FANUC Cassette, press keys as follows :
[AUXILIARY]⇒
R S T R
,
B
INPUT
To input data from FANUC PPR, press keys as follows :
[AUXILIARY]⇒
R S T R
,
P
INPUT
3. Turn off the power once.
6.5
DUMP/RESTORE OF
Symbol CAPi T DATA
6.5.1
Kind of Data in Sub
Memory
6.5.2
Operation
D Outputting data (Dump)
D Inputting data (Restore)
