Series 16i/160i/160is/18i/180i/180is/ Maintenance manual Page 534

Maintenance manual
7. INTERFACE BETWEEN CNC AND PMC
B–63525EN/02
504
Symbol
M
series
T
series
Address Signal name
EC0A to EC6A G143#0 to #6 f f
EC0B to EC6B G155#0 to #6 f f
EC0C to EC6C
Axis control command signal (PMC axis control)
G167#0 to #6 f f
EC0D to EC6D G179#0 to #6 f f
ECKZA F130#1 f f
ECKZB F133#1 f f
ECKZC
Following zero checking signal (PMC axis control)
F136#1 f f
ECKZD F139#1 f f
ECLRA G142#6 f f
ECLRB G154#6 f f
ECLRC
Reset signal (PMC axis control)
G166#6 f f
ECLRD G178#6 f f
ED0 to ED15 Data signal for external data input G000,G001 f f
EDENA F130#3 f f
EDENB F133#3 f f
EDENC
Auxiliary function executing signal (PMC axis control)
F136#3 f f
EDEND F139#3 f f
EDGN Slave diagnosis selection signal F177#7 f f
EF External operationsignal F008#0 – f
EFD External operationsignal for high-speed interface F007#1 – f
EFIN External operation function completion signal G005#1 – f
EFINA G142#0 f f
EFINB G154#0 f f
EFINC
Auxiliary function completion signal (PMC axis control)
G166#0 f f
EFIND G178#0 f f
EGBM1 to EGBM8 EGB mode confirmation signal F208 – f
EGENA F130#4 f f
EGENB F133#4 f f
EGENC
Axis moving signal (PMC axis control)
F136#4 f f
EGEND F139#4 f f
EIALA F130#2 f f
EIALB F133#2 f f
EIALC
Alarm signal (PMC axis control)
F136#2 f f
EIALD F139#2 f f
EID0A to EID31A G146 to G149 f f
EID0B to EID31B G158 to G161 f f
EID0C to EID31C
Axis control data signal (PMC axis control)
G170 to G173 f f
EID0D to EID31D G182 to G185 f f
