B–63304EN/02

4. SUB CYCLE FUNCTION

PROGRAMMING AND

OPERATION BY Symbolic FAPT

177

(Soft keys)

[CURSOR °] [CURSOR ±] These keys are used to select the. .

menu number.

[END] This key is depressed when the sub cycle file has been. . .

created. The display returns to the “family program”

screen.

(3)“Sub cycle detail setting” pattern

The display shifts to the following screen when the sub cycle name is

set.

Set the calling G code, the program number, the address and the

comment of the required argument on this screen.

The G code must always be set. “KEY–IN AGAIN” is displayed if it

is tried to return to the menu screen without defining G code.

The program number should be left undefined if the correspondence

between the calling G code and the called program number is set by

a parameter on the NC side.

Up to 10 arguments are settable. Also the comment is settable in up

to 6 characters. The arguments can be programmed by any addresses

excluding G, L, N, O, and P. For I, J, and K only, they must be

programmed in alphabetical order.

(Soft keys)

[CURSOR °] [CURSOR ±] These keys are used to select the. .

question to be set. Such a method of

feeding as to leave the address

undefined and to define the comment

only is impossible.

[END] This key is depressed when all the settings are over. The. . .

display returns to the preceding “sub cycle menu” screen.
