B–63304EN/02

3. EXECUTION OF

Symbolic FAPT

PROGRAMMING AND

OPERATION BY Symbolic FAPT

NOTE

1 The final element of the figure must be a direction arrow and

the end point defined, before pressing the “FIGURE COPY”

key.

Examples:

Figure element number 1 2 3 4 5 6 7 8. . . . . . .

Figure configuration element ° ²¾² ±² °²j. . .

The element here must be

an direction arrow and the

end point defined.

a) When the element in front is not a direction arrow, if the

soft key “FIGURE COPY” is pressed, the error message

“LAST END POINT IS ARROW” will be displayed and the

copy specification screen will not appear.

b) When the end point of the element is not defined, if the

soft key “FIGURE COPY” is pressed, the error message

“LAST END POINT IS UNDEFINED” will be displayed

and the copy specification screen will not appear.

2 Input a positive whole number between 1 and 10 in the

repeat number. If any other data is keyed in the message

“KEY IN AGAIN” will appear.

3 When there is incremental type data in the copy area, it will

change to absolute type data when copied.

4 When the general element number has been exceeded

during execution of figure copy, as many copies as is

possible will be created. An error message indicating that

“the number of element is excessive” will appear on the

screen.
