ANIMATED SIMULATION FUNCTION B

B–63304EN/02

1. ANIMATED SIMULATION

FUNCTION B

716

By setting appropriate value in the parameter “DRAWING TYPE C =”,

which is included in the “PARAMETER SET”window of the animated

simulation, the simulation picture can be selected as follows.

C=1: Draw X–Z side view on left side and X–C front view on right side

of the screen

=0: Draw X–Z side view on full screen

Following soft–keys are available for animated simulation.

CHECK

START

ORIGI-

NAL

PARAM-

ETER

TOOL

PATH

DRAWNG

RANGE

INTER.

CHECK

END

[CHECK START]

Press to start animated simulation.

[ORIGINAL]

Press to restore blank workpiece figure on the screen.

[PARAMETER]

press to set various parameters relating to the animated simulation.

[DRAWNG RANGE]

Press to increase or reduce the size of the simulation picture on the screen.

This soft–key is not valid and not shown on the screen when simulation

views of both side view and front view are displayed on the screen.

Also, because this soft–key is valid only before the “CHECK START”

soft–key is pressed and it disappears from the screen when “CHECK

START” is pressed, this soft–key must be operated before pressing

“CHECK START” key if magnification or reduction is required.

[TOOL PATH]

Each time this key is pressed, the tool path tracing mode alternates

between ON and OFF.

When ON, tool path traces are drawn on both side view and front view of

the simulation. Tool path tracing mode can be alternated during the

simulation.

While in the interference check mode, the tool path traces are not drawn.

[INTER.CHECK]

Each time this key is pressed, the interference check mode alternates

between ON and OFF. This soft–key disappears when bit 5 of the system

parameter No. 701 is ON(disable interference check).

When the interference check mode is switched ON, tool path tracing mode

is forced to be OFF.

The interference check mode can be changed only before the “CHECK

START”soft–key is pressed. After the key is pressed, pressing

“INTERFERENCE” soft–key does not change the state of the

interference check mode.

[END]

Press to return to the Main Menu.
