C–AXIS FAPT FUNCTION
B–63304EN/02
8. C–AXIS FAPT FUNCTION B
516
Select MENU 6 to perform animated simulation of the created NC
data.Operation of the Animated Simulation is the same as that of C–axis
FAPT FUNCTION. Refer to chapter VIII C–AXIS FAPT FUNCTION,
section 3 ANIMATED SIMULATION, of the OPERATOR’s MANUAL
for CONVERSATIONAL AUTOMATIC PROGRAMMING
FUNCTION FOR LATHE, B–61804E–2.
(1)Material data
Material data necessary for C–AXIS REAMING and C–AXIS
BORING can be specified in the same manner as that of C–AXIS
FAPT FUNCTION.
Specify the following machining conditions marked with “f” in the
table below for high speed tool and/or carbide tool.
Tool type Cutting Speed Feed amount
V
FR (Radial
direction)
FT (Axial
Direction)
Reamer f — f
Boring tool f — f
NOTE
1 The unit of the cutting speed is m/min or feet/min.The unit
of feed rate is m/rev or inch/rev.
2 When “SPECIAL” is selected for TOOL MATERIAL (MT),
actual machining conditions are calculated by multiplying
override value in the system parameter No.321, 322 to the
given machining conditions for carbide tool.
For the details of the definition method,refer to chapter V section 1,
MATERIAL DATA, ofthe OPERATOR’s MANUAL for
CONVERSATIONAL AUTOMATIC PROGRAMMING
FUNCTION FOR LATHE, B–61804E–2.
(2)Tool Data
Tool data necessary for C–AXIS REAMING and C–AXIS BORING
can be specified in the same manner as that of C–AXIS FAPT
FUNCTION.
To define tool data for C–AXIS REAMING or C–AXIS BORING,
specify REAMER or BORE for the parameter, TOOL TYPE,
respecitively.
TOOL TYPE TP= 5: REAMER
6: BORING
Enter following tool shape parameters for Reamer and Bore.
8.2.4
Animated simulation
8.2.5
Material and Tool Data
Previous page
Next page
