APPENDIX

B–63304EN/02

A. SETTING DATA,

SYSTEM PARAMETER, MTF

844

Parameter

No.

Details

Standard

value

Coloring

data type

0621 Character 4 Fixed messages (messages other than questions that invariably appear on

that page and their accompanying messages).

(Example) “1. CYLINDER” display at material select picture.

0622 Character 6 Fixed messages for one page (groups of messages that appear several times

on one page, such as process list).

0623 Character 4 Question message.

0624 – 7 Not used.

0625 Character –3 Question key word and relevant data.

0626 Character –5 “PRESS SOFT KEY” message (with picture fixed).

0627 Character 6 Messages accompanying the message currently under question.

(Example) Accompanying message displayed when EE data is entered at

groove shape input: “(0: LAST 1: NEXT)”

0628 Character 6 Already keyed–in data and numeric data

(Example 1) Color of element symbol displayed on the 2nd line at machining

figure definition picture.

(Example 2) Parameter data and coordinate data display.

0629 Character 7 Main title with no page No.

(Example) “PARAMETER & DATA SET” when “DATA SET” key is pressed

at initial picture.

0650 – 2 Not used.

0651 Character 0 Scale value display ‘S =’

0652 Character 4 T code display ‘T’

0653 Character 1 O No. display “O”

0654 Character 5 NC data.

0655 Character 7 Coordinate display ‘X’, ‘Z’.

0656 Character 4 Cutting time display ‘CUTTING =’.

0657 Character 4 Rapid feed time display ‘RAPID =’.

0660 Graphic 2 Color of blank of animated simulation Do not change the setting

0661 Graphic 4 Color of chuck of animated simulation

0662 Graphic 4 Color of tail stock of animated simulation

0663 Graphic 5 Color of center line of animated simulatio

0664 Graphic 1 Color of tool holder of animated simulation

0665 Graphic 1 Color of tip of turret 1

0666 Graphic 1 Color of tip of turret 2 (TTF only)

0667 to

0669

– Undefined Not used

0670 Character 4 Color of the data programmed on the initial screen data setting screen
