SLANTED SURFACE MACHINING
B–63304EN/02
2. DEFINING PART
FIGURES (MENU NO. 2)
776
(3)On the detail data input screen for each figure type, pressing the
[SLANTED SURFACE SETTING] soft key displays the SLANTED
SURFACE SETTING screen.
ESCAPE BACK
PAGE
SLANTED
SURFACE
SETTING
CHECK
CURSOR
"
CURSOR
#
NEXT
PAGE
(For other than arbitrary slanted surfaces)
ESCAPE BACK
PAGE
SLANTED
SURFACE
SETTING
CHECK
CURSOR
"
CURSOR
#
NEXT
PAGE
(For arbitrary slanted surfaces: Screen for entering the start–point)
NOTE
No slanted surface can be specified for Y–axis end facing
figures.
(4)On the SLANTED SURFACE SETTING screen, set up the slanted
surface rotation center O’ (Z, DX), slant angle A, and safety height
from the slanted surface. Pressing the [END] soft key resumes the
previous detail data input screen.
