B–63304EN/02

1. VARIOUS FUNCTIONS OF

Symbolic FAPT

VARIOUS FUNCTIONS AND

PRECAUTIONS OF Symbolic FAPT

335

NOTE

1 If, on the tool data setting screen for machining definition,

the answer to the prompt asking whether to invert the

X–axis is set to 1 (yes), a machining area is not

automatically set, even when the automatic process

determination option is enabled. The cutting direction and

dividing direction should be defined manually.

2 The automatic process determination function cannot be

used to define a process in which the X–axis is to be

inverted. (Using the automatic process determination

function generates those processes in which the X–axis is

not to be inverted.)

3 On menu 5, the [ANIMATION] soft key does not appear.

When an NC data is prepared, only those machining

operations indicated by line drawing are shown.

4In 16–TC CAP II, 16i–TA CAP II, and Symbol CAPi T,

gradation display is disabled for animated simulation on

menu 6.

5 In the following cases, the prompt asking whether to invert

the X–axis does not appear on the tool data setting screen

for machining definition.

(1)When C– or Y–axis machining is specified

(2)When the back machining function is set

(3)When the workpiece inversion function is set
