C–AXIS FAPT FUNCTION
B–63304EN/02
8. C–AXIS FAPT FUNCTION B
518
(1)Process parameters
No. Format Initial value Description Remarks
0316 0,1
designation
(8 bits)
00000000 Single Step parameter for C–AXIS REAMING
Bit 0 Start of process
Bit 1 Just before approach
Bit 2 Just before return relief
0 : Do not stop.
1 : Stop
7 6 5 4 3 2 1 0Bit
0317 0,1
designation
(8 bits)
00000000 Single Step parameter for C–AXIS REAMING
(Same as parameter No.316)
(2)Machining Parameters
No. Format Initial value Description Remarks
0380 0,1
designation
(8 bits)
00100100 C–AXIS REAMING PARAMETER
Bit 1 Coolant
0 : Do not use
1 : Use
Bit 2 Cancel tool offset
0 : Do not output
1 : Output
Bit 3,4 Approach
00 : 1 axis at a time
01 : 2axis simultaneously
10 : 3 axis simultaneously
Bit 5 Return relief (X,Z axis)
0 : 2 axis simultaneously
1 : 1 axis at a time
Bit 7 Setting window for passing point
0 : Do not show
1 : Show
7 6 5 4 3 2 1 0Bit
0381 0,1
designation
(8 bits)
00100100 C–AXIS REAMING PARAMETER
(Same as parameter No.380)
8.3
PARAMETERS
8.3.1
System Parameters
