B–63304EN/02
7. IN–FEED MACHINING IN C–AXIS
FACE MILLING PROCESS
C–AXIS FAPT FUNCTION
495
The following system parameters have been added.
No. Format Initial value Description
372 Real number 0.2 Rate of cutting along the X
axis upon C–axis notching
(rate to the tool diameter)
373 Real number 0.5 (mm specification)
0.02 (inch specification)
Finishing allowance along the
Z axis upon C–axis notching
No MTF parameter is added to this function.
Use conventional MTF parameters.
(Bit 0 of MTF parameter No. 1305 can be used as usual to specify whether
to create NC data with the conversational program by considering cutter
compensation or to create NC data by using the NC cutter compensation
function.)
7.3
SYSTEM
PARAMETERS
7.4
MTF
