Symbol CAPi T Operators manual Page 785

Operators manual

Page of 990

/ 990

B–63304EN/02

1. CAP II FOR TWO–PATH

LATHE WITH TWO

OPPOSING SPINDLES

CAP II FOR TWO–PATH LATHE

WITH TWO OPPOSING SPINDLES

765

No. RemarksDescriptionInitial valueFormat

0746 Integer Undefined M–code to delete work piece figure in the secondary machining win-

dow.

JUser for animated machining simulationK

New

0800 0 or 1

(8 bits)

00001100

Bit 0 Define comments for arguments of a sub–cycle by;

0 : Alpha–numeric characters.

1 : Character codes.

Bit 1 In the “SUB CYCLE” window under the “MACHINING

DEFINITION” window, “POS.1 MACHIN” soft–key is;

0 : Not available.

1 : Available

Bit 2 In the “SUB CYCLE” window under the “MACHINING

DEFINITION” window, “POS.2 MACHIN” soft–key is;

0 : Not available.

1 : Available

Bit 3 In the “TOOLING INFORMATION” window or the “TOOL DATA”

window under the “MACHINING DEFINITION” window, when

tooling tools onto secondary turret;

0 : Tool data and/or holder data is copied as is, without

reversing.

1 : Tool data and/or holder data is reversed around X–axis and

copied.

Bit 4 In the “SUB CYCLE” window under the “MACHINING

DEFINITION” window, when arguments are left undefined;

0 : Addresses corresponding to undefined arguments are not

output in part program.

1 : Addresses corresponding to undefined arguments are

output in part program with the value of “0”.

7 6 5 4 3 2 1 0Bit

New

No. Format Initial value Description

1050 Integer 2 Number of turrets (1 or 2)

1: 2 axis lathe (1 spindle/1 turret or 2 spindle/1 turret)

2: 4 axis lathe (1 spindle/2 turret or 2 spindle/2 turret)

1055 Integer 2 Turret types

0: Ordinary 2 axis lathe

1: 2 axis lathe with reversible X–axis (Chasing tool type turret etc.)

2: 4 axes lathe

1130 Integer 3 M–code for primary spindle CW (primary machining)

1131 Integer 4 M–code for primary spindle CCW (primary machining)

1132 Integer 5 M–code for primary spindle stop (primary machining)

1315 Integer –1 M–code for primary spindle milling start (primary machining)

1316 Integer –1 M–code for primary spindle turning start (primary machining)

1351 Integer 68 M–code for primary spindle C–axis clamp (primary machining)

1.3.2

MTF
