Parameter No. RemarksMeaning
2226 Start of C–axis reaming (Only for 5900 and 5F00 systems)
2227 Start of C–axis boring (Only for 5900 and 5F00 systems)
2230 End of C–axis center drilling (Only for 5900 and 5F00 systems)
2231 End of C–axis drilling (Only for 5900 and 5F00 systems)
2232 End of C–axis tapping (Only for 5900 and 5F00 systems)
2233 End of C–axis grooving (Only for 5900 and 5F00 systems)
2234 End of C–axis notching (Only for 5900 and 5F00 systems)
2235 End of C–axis cylindrical grooving (Only for 5900 and 5F00 systems)
2236 End of C–axis reaming (Only for 5900 and 5F00 systems)
2237 End of C–axis boring (Only for 5900 and 5F00 systems)
2240 C–axis interpolation tapping cycle block (1)
2241 C–axis interpolation tapping cycle block (2)
2242 Block for canceling a C–axis interpolation tapping cycle
2243 Y–axis interpolation tapping cycle block (1)
2244 Y–axis interpolation tapping cycle block (2)
2245 Block for canceling a Y–axis interpolation tapping cycle
2252 Starting three–dimensional coordinate conversion G68.1 Xx Yy Zz Ii Ji Kk Rr
2253 Canceling three–dimensional coordinate conversion G69.1
2254 Outputting T code for tool selection G0 Txxxx
2255 Starting lathe turning process G700 Hh M17 Bb Ii
2256 Starting milling process G700 Hh M18 Bb
2300 Output of the special function code Number of codes that can be set: 10
2301 Output of the special function code Number of codes that can be set: 10
2302 Output of the special function code Number of codes that can be set: 10
2303 Output of the special function code Number of codes that can be set: 10
2304 Output of the special function code Number of codes that can be set: 10
2305 Output of the special function code Number of codes that can be set: 10
2306 Output of the special function code Number of codes that can be set: 10
2307 Output of the special function code Number of codes that can be set: 10
2308 Output of the special function code Number of codes that can be set: 10
2309 Output of the special function code Number of codes that can be set: 10
