Symbol CAPi T Operators manual Page 354

Operators manual
VARIOUS FUNCTIONS AND
PRECAUTIONS OF Symbolic FAPT
B–63304EN/02
1. VARIOUS FUNCTIONS OF
Symbolic FAPT
334
(a) Define the parts figure on the X–axis plus side.
(b)Set the turret position to (ZI) when T01 is the reference tool.
(Undefined for value of X axis).
(c) Define the rough cutting process of outer diameter (Tool: T01)
Input
INPUT
only when the system asks you the following question
after setting the machining start position in X and Z axis direction.
INVERT X COORDINATE?
INVX =_ (1: YES 0: NO)
Define the machining area of outer diameter.
(d)Roughly cut the inner diameter on the X–axis minus side by using
T02 tool. Don’t set the value to the question for X–axis machining
start position.
Input 1
INPUT
to indicate that the workpiece is cut on the X–axis
minus side during this process to the question as same as (c).
Define the machining area of inner diameter.
(e) Prepare NC data.
(7)Warnings and Notes
WARNING
1 Be careful with the setting of the spindle rotating directions
of system parameters No.0107 to 0115.
2 The results of answering the system question about the
X–axis inversion are as specified below according to the
setting of MTF No.1051 (turret position).
MTF No.1051 should be interpreted ”whether the reference
tool is positioned on the X–axis plus side or on the X–axis
minus side”.
7
not used
6 5 4
0/1
3
0/1
2
0/1
1
0/1
0
0/1
Spindle rotating direction when cutting is done
on X–axis plus side
Spindle rotating direction when cutting is made
on X–axis minus side
Set values mean as follows.
0 : M code No.MTF1130 (standard M03)
1 : M code No.MTF1131 (standard M04)
MTF No.1051
Answer to question of X–axis inversion
MTF No.1051
setting
0: No 1: Yes
1
Output on X–axis plus
(+) side
Output on X–axis minus
(–) side
–1
Output on X–axis minus
(–) side
Output on X–axis plus
(+) side
