PROGRAMMING22. RISC PROCESSOR
B–63534EN/02
624
S 3–dimensional tool compensation –G41
S Wheel wear compensation –G41
S Tool offset –G45,G46,G47,G48
S Local coordinate system –G52
S Machine coordinate system –G53
S Single direction positioning –G60
S Automatic corner override –G62
S Tapping mode –G63
S Macro call –G65,G66,G67
(SubProgram call is available)
S Figure copying –G72.1,G72.2
S Simple electric gear box –G80,G81
S Functions for hobbing machine –G80,G81
S External operation function –G81
S Chopping function –G81.1
S Setting a workpiece coordinate system –G92
S Workpiece coordinate system preset –G92.1
S Feed per revolution –G95
S Constant surface speed control –G96,G97
S Infeed control –G160,G161
The following functions can not be used in the AI High Precision Contour
Control mode or AI NANO High Precision Contour Control mode.
S Flexible synchronous control
S Sequence number comparison and stop
It is not possible to stop by the sequence number in the AI High
Precision Contour Control mode or in the AI Nano High
Precision Contour Control mode.
S Index table indexing
S Retrace function
Do not use retrace function in the program which uses the AI
High Precision Contour Control mode or the AI Nano High
Precision Contour Control.
S Rotary axis control
S Gentle curve normal direction control
S Tool life management
Tool life value is counted in the AI High Precision Contour
Control mode or in the AI Nano AI High Precision Contour
Control mode. However , do not use the command related to the
tool life management function.
S Macro executor (Execution macro)
S Manual handle interruption
D Restriction –4
